Scope Mounting for
Winchester Pre 64 Model 70
Step 1: Date your Winchester using the button below.
Step 2: Choose a scope from the year your Model 70 was built, or later.
Winchester Model 70 Scope Favorites
Introduced in 1956, the Weaver K4-60B brought constantly centered reticles to the Weaver line. We put this K4 scope on rifles from 1956 to the late 60’s in place of the poorly built 60C through F models. Like all of our restored scopes, it is restored using all original Weaver parts but modern glass, glues, seals, and lubricants. This is the best in the series of the most popular scope ever made!
Today’s expected ship time: Immediate
Using all original Lyman scopes and parts, then adding modern glues, seals and lubricants, we’ve rebuilt this Lyman scope to be better than new. Re-sealed, nitrogen processed, re-finished, and internally cleaned. This model comes blued with crosshair reticle.
Specifications of the Lyman Alaskan include a 2.5 power optic in a 7/8 inch blued steel tube. Lyman Alaskan adjustment is accomplished with internal scope click adjustments at ½” per click at 100 yards. The turrets are covered with screw-on steel caps.
Today’s expected ship time: 60 days
If we are currently out of stock please join our waitlist by entering your email address below. We’ll notify you when it is in stock.
Using all original Weaver scopes and parts, then adding modern glues, seals and lubricants, we’ve rebuilt the Weaver scopes to be better than new. Re-sealed, nitrogen processed, re-finished, internally cleaned with optional color case hardened accents and choice of upgraded reticles. Standard model comes blued with crosshair reticle. The 60-B is the centered reticle version of the K10. It was introduced in 1956.
Today’s expected ship time: Immediate
If we are currently out of stock for the combination you are shopping for please join our waitlist by selecting the appropriate options from the dropdown and entering your email address. We’ll notify you when it is in stock.
Olive drab matte finish.
Using all original Weaver scopes and parts, then adding modern glues, seals and lubricants, we’ve rebuilt the Weaver scopes to be better than new. Re-sealed, nitrogen processed, re-finished, internally cleaned with optional color case accents and choice of upgraded reticles. The standard model comes blued with a crosshair reticle.
Today’s expected ship time: 45 days
If we are currently out of stock for the combination you are shopping for please join our waitlist by selecting the appropriate grade from the dropdown and entering your email address. We’ll notify you when it is in stock.
Step 3: Choose your Redfield, Weaver or Buehler rings and bases.
Redfield Top Mounting
Bases: Below Serial #66,350 except .300 and .375 select JR 70 from dropdown menu on product page.
Below Serial #66,350 .300 and .375 select JR 70 M.
Win 70 Target select JR AM.
.300 and .375 above serial #66,350 select JR AM.
Above serial #66,350 except .300 and .375 select JR A
Above serial #66,350 .300 and .375 select JR AH
Rings: Low for under 40mm obj. Med for 40-48mm obj. High for 50-56 Obj.
Square Machined Steel Early Redfield bases with Redfield and Patent No. stamped on the side for your period-perfect builds from the 1930’s to the 1950’s.
New old stock and refurbished inventory: some new old bases may have ring marks in the dovetail from originally having rings installed at the factory.
Please see list below for specific application before choosing a base from the drop-down menu or click here to reference Redfield base charts.
Packaging varies. Some models also available with folding peep - see drop-down for availability.
Please see list below for specific application before choosing a base from the drop-down menu or click here to reference Redfield base charts.
Also found here is the Redfield SA-22 Cantilever Barrel Base mount for Browning SA-22.
Ring Heights:
Low .152"
Medium .272"
High .402"
Standard rear/front.
Ring Heights:
Low .152"
Medium .272"
High .402"
1” Ring Heights:
Low .152"
Medium .272" (for 44-50mm objective diameters)
High .402" (for 50-56mm objective diameters)
26 & 30mm Ring Heights:
Medium .394"
High .492" (for objective diameters up to 56mm)
Packaging may vary.
Weaver Top Mounting
Bases: Below serial # 66,350 select top mount bases 48 and 46 from dropdown menu.
Above serial #66,350 .300 and .375 select 49A and 46
Above serial #66,350 all calibers except .300 and .375 select 46 and 47
Rings: Low for under 40mm obj. Med for 40-48mm obj. High for 50-56 Obj.
New old stock. Various packaging.
Please see list below for specific application before choosing a base from the drop-down menu where they are organized numerically.
Saddle thickness:
Low: .095”
Medium: .175”
High: .34”
A Vintage Gun Scopes Original. The best way we know to bring new life to your old Weaver scope.
Saddle thickness:
Low: .095”
Medium: .175”
High: .34”
Weaver Side Mounting
Weaver N Mounts (for 3/4 tube scopes only): Select N1 (low) or N4 (high) from dropdown menu on product page.
Weaver Detachable Side Mounts: Base: Select side mount 1 from dropdown menu on product page.
Detachable Side Mount Rings: Select low for scopes 38mm and under objective. Select high for scopes 40-48mm.
Available models include: N1, N2, N3, N4, and N5.
New old stock. Various packaging. Compatible with Weaver Detachable Side Mount Rings and Weaver Detachable Long Side Mount Rings.
Please see list below for specific application before choosing a base from the drop-down menu where they are organized numerically.
Compatible with Weaver Side Mount Base.
Weaver Pivot Mounting (Swing Away to Access Iron Sights)
Base: Below Serial #66,350 Select 138 and 135 for scopes with objective diameters 1.355” or less. from the dropdown menu on product page below. Select 146 and 149 for scopes up to 1.445” objective diameter.
Rings: Low for under 40mm obj. Med for 40-48mm obj. High for 50-56 Obj.
New old stock. Various packaging.
Use with Weaver Pivot Mount Rings.
Please see list below for specific application before choosing a base from the drop-down menu where they are organized numerically.
A Vintage Gun Scopes original. The best way we know to bring new life to your Weaver scope.
Use with Weaver Pivot Mount Bases.
If we are currently out of stock please join our waitlist by entering your email address below. We’ll notify you when it is in stock.
Buehler Mounting
Bases:
Micro Dial: Above serial #66,350 select code 70U from the dropdown menu on product page below.
Below serial #66,360 select code 54U.
Two Piece Base: Below serial #66,350 select code W4
Above serial #66,350 select code W
Rings: Code 6 for under 40mm obj. Code 7 for 40-48mm obj. Code 8 for 48-56 Obj.
New old stock. Various packaging.
Please see list below for specific application before choosing a base from the drop-down menu.
New old stock unless otherwise noted. Various packaging.
Please see list below for specific application before choosing a base from the drop-down menu.
Code 5: 7/8”, Low
Code 6: 1", Low
Code 7: 1", Medium
Code 8: 1", High
Code 10: 26mm, Standard
Code 11: 26mm, High
Code 14: 26.5mm, High
Code 16: 28mm, Standard
Stith Mounts (for undrilled receivers)
Griffin and Howe Mounts
No-drill and QED mounting system, perfect for that vintage rifle that has not been tapped. New old stock includes the following models. Check the drop-down box for availability.
Savage 99
Winchester 94
Winchester M-70
